How to use the Spin Coater Syringe Adapter

Name: How to use the Spin Coater Syringe Adapter
Uploaded: 2023-04-19
Duration: 24 s
Description: How to use the Spin Coater Syringe Adapter

Spin coating is one of the most popular techniques for creating thin-films. The method is quick, accurate, and easy to control. A spin coater like the Ossila Spin Coater allows you to control the spin speed and save recipes with up to 50 steps, and therefore allows you to create films of various thicknesses. However, without a syringe pump, the solution must be manually dispensed (typically by using a pipette) and it is therefore difficult to control the rate, volume, and timing with which the solution is applied to the substrate. This makes it difficult to accurately reproduce a given experiment. In addition, a number of advanced spin coating techniques require set volumes of multiple different solutions to be added at controlled rates, at different times during the process.

The new adapter for the Ossila Spin Coater allows up to four separate streams of solution into the Spin Coater through the provided tubing, along with a hole for standard coating through the centre. By combining the syringe pump and spin coater, complex multi-step processes can be easily carried out with a high level of repeatability.

Instructions for using an Ossila syringe pump with the Ossila Spin Coater:

Place the substrate into the Spin Coater chuck and then insert the Spin Coater Syringe Adapter.
Attach the needles to the dispensing tubes.
Insert up to four needles into the adapter. It is designed for needles that are 2.5cm (1 inch) in length.
Attach the dispensing tubes to each syringe in the Syringe Pump.
Enter your experiment settings, then press 'Start' on the Spin Coater and Syringe Pump.
Using the Dual version of the Syringe Pump, solutions can be alternated and dispensed at different flow rates.
The attachment also features an opening in the centre to enable precise solution deposition for manual dispensing.
