Tin (IV) Oxide Powder
CAS Number 18282-10-5
Charge Transport Layer Materials, Electron Transport Layer Materials, Inorganic Electronic Materials, Metal Oxides
An n-type semiconducting metal oxide powder
as an electron transporting material in perovskite solar cells and DSSCs, SnO2
Overview | Product Information | Related Products
Tin (IV) oxide (CAS number 18282-10-5), also known as stannic oxide, is a metal oxide widely used as an electron transporting material in solar cells. Tin oxide shows high electron mobility up to 260 cm2/V·s and a bandgap of 3.6 – 4.0 eV.
The HOMO level of tin oxide powder is typically at −7.36 eV, resulting in a large valence band offset at the interface between the perovskite and the tin oxide layer. This is desirable to block hole transport and preventing charge recombination, resulting in higher power conversion efficiency.
Perovskite solar cells using tin oxide as the electron transport layer have achieved a champion PCE of 24.63%, accompanied by a short-circuit current density (JSC) of 25.49 mA/cm², an open-circuit voltage (VOC) of 1.17 V, and a fill factor (FF) of 82.56%. The particle-to-particle interaction of tin oxide can be improved by adding phase-transfer materials, such as phenyltrimethylammonium chloride, which enhances the coverage on flexible substrates and ultimately improves the PCE.
An electron transfer material
with high electron mobility
Desirable band structure
Efficiently blocking hole transporting
Worldwide shipping
Quick and reliable shipping
High Purity
99.99% pure
General Information
| CAS Number | 18282-10-5 |
|---|---|
| Chemical Formula | SnO2 |
| Full Name | Tin dioxide |
| HOMO and LUMO |
−7.36 eV (HOMO) −3.78 eV (LUMO) |
| Molecular Weight | 150.71 g/mol |
| Melting Point | 1630 °C |
| Synonyms | Tin oxide, Stannic oxide, Stannic dioxide |
| Classification or Family | Metal oxide, Electron transport layer, Electron selective layer, Perovskite solar cell, DSSCs, Hole-blocking layer |
Product Details
| Purity | 99.99% |
|---|---|
| Particle Size | 30 – 50 nm |
| Appearance | Light yellow powder |
MSDS Documentation
Tin (IV) Oxide MSDS SheetReferences
- Efficient planar perovskite solar cells using passivated tin oxide as an electron transport layer, Y. Lee et al., Adv. Sci., 5, 1800130 (2018); DOI: 10.1002/advs.201800130.
- Tin oxide electron selective layers for efficient, stable, and scalable perovskite solar cells, C. Altinkaya et al., Adv. Mater., 33, 2005504 (2021); DOI: 10.1002/adma.202005504.
- Slot-die coating of electron transport layers for perovskite solar cells using water and butanol-based tin oxide dispersions, A. Vijayan et al., Mater. Adv., 5, 4430 (2024); DOI: 10.1039/d4ma00351a.
